3 Axis Plastic Brush Tufting Machine Made in China
The machine includes 2 drilling heads and 1 hair tufting head to produce brushes. The replacement platform can produce disc brush, round roller brush, broom, toilet brush, etc.
Description
Types of brush tufting machine:
Drilling/brush tufting machines can be divided into different types according to different classification standards. According to the number of axis, it can be divided into two axes, three axes and more than four axes; according to the function, it can be divided into brush tufting machine, drilling machine and drilling and tufting integrated machine. At present, two-axis and three-axis machines are commonly used, because most products only need to use two-axis and three-axis machines, and machines with more than four-axis are used to produce some special-shaped brushes.
Technical data:
Number of axes | 3 |
Tufting heads | 1 |
Heads of drilling | 2 |
Maximum speed(hole/min) | 500 |
Maximum length of brush piece(mm) | 600 |
Filament length range(mm) | 40-80 |
Hole diameter range(mm) | 1.8-4 |
Rated voltage/frequency(V.Hz) | 220V, 50Hz |
| Power of engine(KW) | 2.5 |
Weight(KG) | 1900 |
Dimensions(L*W*H)(mm) | 2400*1950*2050 |
